1 CH 7 Inch LCD COFDM Receiver , Audio Video Receiver With High Definition Multimedia Interface BNC Port

  • 1
  • 2
  • 3

Model Number : ST6201Rmini-P

Place of Origin : Shenzhen, China

Brand Name : SUNTOR

Certification : FCC, CE, RoHS

MOQ : 1 set

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 set/ month

modulation : COFDM

Receiving Frequency : 300MHz～4.4GHz

bandwidth : 2/2.5/4/8MHz

resolution : 1080P

LCD display : 7 Inch

Video Output : High Definition Multimedia Interface / BNC

Weight : 1.4kg

Size : 240*180*80mm

Contact Now

Mini Portable 1 CH 7 inch LCD HD 1080P COFDM video receiver with High Definition Multimedia Interface BNC port

Introduction

ST6201Rmini-P is a new generation of HD Portable wireless video receiving system for real-time. It adopts the leading COFDM modulation technology with narrow band of frequency occupied(2/2.5/4/8Mhz) and a strong anti-multipath interference ability. Combining with advanced diversity reception technology which overcome Image transmission multi-path reflection and shade difficulties brought out by the conventional analog technology and modulation techniques. This technology makes the high-speed video capture and HD image receiving in real-time in NLOS environment. It uses H.264 video decoding standard. The definition is Full HD 10180P, and resolution 1920 * 1080 compatible 1080I, 720P, 480P and SD. Support digital High Definition Multimedia Interface, CVBS and Ethernet output port. It integrate 3G/4G Relay image transmission, duplex two-way voice communication and high capacity Memory function. It has a fine quality, excellent fineness and rich color.

Features

  • Resolution: HD 1080P(1920*1080)
  • Built-in 7 inch all view LCD to real time display video and audio
  • Support 1 channel display at same time.
  • Built-in DC 12V lithium battery can working up to 5 hours
  • Support High Definition Multimedia Interface, CVBS & Ethernet output
  • Manually set up a dual AES encryption
  • Built-in LCD to display and manually adjust parameters
  • LCD to show Signal strength and power station by percent numbers.
  • Operating frequency band 2 / 2.5 / 4 / 8MHz Adjustable on LCD
  • Dual antenna receiving, stable signal and smooth image
Modulation Receiving Frequency 300MHz～4.4GHz
Frequency Band 2/2.5/4/8MHz
Modulation COFDM (64QAM, 16QAM, QPSK)
Receiving Sensitivity ≤-100dBm @ 4MHz, ≤-97dBm @ 8MHz
Signal Strength Display on LCD
Encryption mode AES 128Bit/SUNTOR Basic Scrambling
System Receiving Polarization Vertical polarization, Dual antenna
Receiving Technology Space Diversity Technology
Filtering technologies Built-in high-performance cavity filter technology
Audio and video Compression format H.264(Embedded Audio)
HD Video Output High Definition Multimedia Interface
SD Video Output BNC
Audio Output Audio R+L Or High Definition Multimedia Interface
Image resolution

HD1080P(1920*1080), compatibility 1080I,720P,480P and standard

resolution
Ethernet Output IE or software to monitor the audio & video
Image frame rate Standard 24/50/60f/s compatible with other frame rate
Others Antenna Double 7.5db omni Antenna
Antenna Connectors 2* SMA ports
Power supply

1. AC220V

2. DC12V(Built-in 12V high capacity lithium battery)
LCD display 7 Inch
Size 240*180*80mm
Weight 1.4kg

1 CH 7 Inch LCD COFDM Receiver , Audio Video Receiver With High Definition Multimedia Interface BNC Port
